BROTHER CYCLES MEHTEH FRAMESET X-SMALL (49cm)

The Mehteh is a Reynolds 725 steel gravel frame – a fast and agile drop bar bike, designed for long days in the saddle on varied terrain.

Brother Cycles has pushed the tyre clearances beyond what you’d find on the average gravel bike giving the option of taking your ride even further off-road. Whether that’s an after work gravel dash or a full blown bikepacking adventure.

Specifications:

• Frame Tubing:
• • Reynolds 725 Heat Treated Chromoly
  • Double-Butted Main Triangle
  • ED Coated
• Fork:
• 1.5 - 1 1/8" Tapered Steerer Full Carbon Disc Fork
• Mudguard Mounts

• Triple Cage Mounts
• 12 x 100mm TA (Included)
• Brake Compatibility: Flat Mount (Max Rotor Size: 160mm)
• Rear Dropouts: 12 x 142mm TA (Included)
• Seatpost Diameter: 27.2mm
• Seat Clamp Diameter: 30mm (Included)
• Headset (Not Included):
• Upper: 44mm, ZS44/28.6
• Lower: EC44/40
• Front Derailleur Clamp Diameter: 28.6mm
• Chainring Clearance:
• 52-39-30T Triple
• 50-34T Double
• 48T Single
• Bottom Bracket Shell: 68mm (ISO)
• Maximum Tyre Clearance:
• 700c X 45mm
• 650b X 2.1"
• Other Features:
• Full-length cable housing guides for derailleurs and brakes
• Stealth dropper post routing
• 3 sets bottle cage mounts on all sizes
• Rear rack and mudguard mounts
• Weight:
• Frame (Medium): 2.2kg
• Carbon Fork (Uncut): 0.55kg

Please contact us directly if you would like the Steel Gravel Fork option.
